EagleX portable drone detection and positioning integrated system cracking adopts cognitive radio protocol (Cognitive Radio Protocol Cracking) CRPC + message-level protocol parsing technology to solve the problems of low-altitude detection and identification, early warning positioning, and trajectory tracking of drone security systems.
The system can passively detect drones in the protected area, distinguish between enemies and friends, and carry out precise strikes, and give the flight direction of the drone. At the same time, it determines the direction through CRPC message-level protocol parsing, locates the target drone and pilot in real time, and tracks the flight trajectory of the drone in real time. It is suitable for low-altitude security defense of aviation airports, prisons, important industrial facilities, national defense and military industry, public security border stations, stadiums, and major events.
Cognitive radio protocol cracking technology is the fourth-generation drone defense method. This part monitors the radio environment in the defense zone 24 hours a day through an antenna array. Collect radio signals in the defense zone, transmit the collected signals to the signal processing unit, accurately demodulate and crack the drone signals, and then transmit the analyzed drone signals to the data server through the network. The data server uniformly manages the received drone signals and conducts defensive strikes on "illegal" drones.
Deployment and use of equipment
Choose a wide-view field outdoors and start deploying and using equipment. Before using the equipment, first
check the specifications and quantities of all parts and standard parts according to the equipment list, and then
assemble step by step according to the installation steps below.
Equipment usage environment
Choose a suitable site outdoors and unfold the equipment for use. It is usually selected in a relatively open high
ground outdoors or on the top of a building. When using it, you need to pay attention to whether there are
obvious obstructions or buildings with strong interference equipment.
Antenna connection
Screw the receiving frequency band antennas to the radio processing unit clockwise one by one according to
the corresponding interfaces marked on the antenna and radio processing unit. Antennas in the same
frequency band can be used universally, but detection antennas in different frequency bands cannot be used
universally.
Note: Different devices may have slight differences. When connecting the antenna, the antenna and radio
processing unit must be connected according to the interface identification. Otherwise, the radio processing unit
will be damaged after the system is turned on.
